LY300 CMY Moving Head Light with CMY/Spot/Beam/Wash for entertainment events

LY300 CMY is a CMY Moving Head Light that integrates beam, Spot and wash effect; Using a 300W LED high brightness light source, zoom from 5° to 45°,  equipped with a CMY colorful infinite mixing system, and combined with dynamic dual prisms  that can be stacked and flexibly used. Good using in music concert and entertaiment evets.

Specification
Input voltage: AC200-240V 50/60Hz
Input power: 500W
Light source: 300W  high brightness LED
LED lifespan: 50000 hours
Color temperature: 7500K
Optical lens: High definition optical lens coated with anti reflective film, with an output lens diameter of 130mm
Zoom: 5 ° -45 °

Color
Equipped with CMY color infinite mixing system
1 color wheel: 7 colors+CTO color temperature correction (adjustable from 2800K-6500K), can achieve bidirectional color flow rainbow effect

Gobo system
1 fixed gobo wheel with 11 gobo and white, with flowing and shaking effects
1 rotating gobo wheel with 7 gobo (insertable) and white, rotating and gobo wheel positioning
Effect configuration
Frost: Independent frost, spot angle 5 ° -45 °
Dimming: 0-100% mechanical linear adjustment
Strobe: 0.5 to 14 t/s.
2 Prism: 4-facet circle prism+4-facet line prism,  can rotating.
Pan: 540 °, 16 bit  finea
Tilt：260 °, 16 bit fine
Control channel: 22/27 channels
Operation mode: voice control, auto run, master-slave, DMX512
Control protocol: Standard DMX512, RDM function
Menu display: 2.4-inch color LCD touch screen;
Product size: 325 * 250 * 630 (mm)
Net weight: 16.5Kg
Working environment temperature:- 20℃~40℃
Protection level: IP20
